Newsletter Vol.58


Grinding Case
Grinding Case
  • Work Piece: Precision Ceramics
  • Model: Double Spindle Grinding Machine JHD-3205IO
  • Maximum grinding diameter: Ø320mm (Ø12.5”)
  • Length of workpiece: 200mm(Ø 7.8”)
  • Diameter of center hole: Ø6~200mm
  • Applicable for high-precision grinding processes with complex workpieces
  • Applicable Industries :
    Applicable Industries :Motor vehicles and other transportation
    Energy, precision machine tool components
    Air / hydraulic components, precision measuring instruments
    Electronic, optical instruments
Machine Overview
Machine Overview

| Centerless Precision Automated Solution |

The JHC-18H-NC3 centerless grinder features a hydrostatic grinding wheel spindle that offers highrotational accuracy, excellent rigidity, smooth operation and long service life.

(1)The NC 3-axis design includes the worktable feed and automatic wheel dressing, enabling fully automated thrufeed grinding and maximizing production efficiency.

(2)Equipped with an NC simple HMI, allowing intuitive operation for the operator.

(3)Equipped with an automated thrufeed loading and unloading device and the off-line gauging,non-contact O.D. measuring system. The system provides real time feedback of post-grinding dimensions to the machine for compensation. Measuring data is also displayed on the machine connected dashboard system for analysis, ensuring consistent grinding quality.

JHC series centerless grinders are ideal for processing cylindrical workpieces such as shafts, rods, piston pins, guide pins, and bearings. These machines are built to meet the demanding requirements of precision mass production.

Coming Exhibitions

— Exhibition —
2025 SEMICON TAIWAN

— Date of exhibition —
Sep.10 - 12 , 2025 ( Wed.- Fri.)

— Location —
TaiNex 2 | 1F

— Booth —
P5412 (TMBA Smart Team)

— Exhibition —
2025 EMO Hannover

— Date of exhibition —
Sep. 22 - 26 , 2025 ( Mon. - Fri. )

— Location —
Messegelände Hannover, Germany

— Booth —
Hall 11 | F71

Holiday Notice
Holiday1

Our office will be closed in May 30 to June 1 due to the Dragon Boat Festival in Taiwan. Please leave your message and we’ll respond to your at once when return. Thank you for your understanding & continuous support.
