Newsletter Vol.38

Feb. 16 2022

News Letter

Newsletter Vol.38

Products | News | Video | Contact Us


Grinding Case


JHC-12S




Workpiece: Quartz / Glass



Model: JHC-12S Centerless Grinding Machine



Standard work rest (diameter): Ø1~25mm



Grinding wheel size (diameter*width*hole): Ø305*150*Ø120mm



Regulating wheel size (diameter*width*hole): Ø205*150*Ø90mm



Regulating wheel speed: Variable speed servo moto



Surface roughness: RA 0.25



Precision mechanical structure



High machine stability



High precision guaranteed




In-feed or thru-feed grinding are both available depends on the requirement workpiece



Equip with our own design loading / unloading device to improve production efficiency

More Applications
....................................................................................................................................................................

Machine Overview
| JHC-18 Centerless Grinding Machine Automation Solution |

JHC-18

The feature of hard metal such as tungsten steel is high hardness, good strength, not easy to wear but brittle. It covers a wide range of application from machine tools, aerospace industry parts, drilling tools, precision bearings and metal molds...etc. According to the characteristics of tungsten steel and customer's production request, we used JHC-18S and JHC-18S-CNC6 two machines equipped with automatic load-unload devices to proceed through grinding. These parts will be inspected and sorted by the off-line gauging workstation at the final step. This solution is to keep high efficiency and high precision of grinding process by fully automatic system.
Machines are also equipped with a real time production monitoring system which is convenient for the visual management. It helps customer forward to the next stage of smart manufacturing.


More Products
....................................................................................................................................................................

Bulletin Board
| HIWIN’s Visit For Shooting Marketing Video |

A new year has begun. Our good neighbor HIWIN Technologies Corporation came to shoot machine videos for marketing project.
To set up the background lighting and camera, to confirm shooting scenes and scripts...HIWIN and JAINNHER checked every detail together. "Actually we were helping our marketing department. We were very unfamiliar with these shooting things at first, but we've getting used to it lately.” HIWIN's R&D staff said with a smile.


Industry Innovation Program interview▲HIWIN & JAINNHER were in the video shooting place

Supply chain disruptions became a regular issue of manufacturing in the post-pandemic world. Manufacturers will need more automation equipment in response to the labor shortage. JAINNHER remains committed to provide turnkey solutions to all customers. For example, JHT Thread Machine equipped with "Smart Machine Function" can detect the properly grind timing, or JHI Internal Machine equipped with "intelligent 4.0 ballscrew" in cooperation with HIWIN. The sensors inside will collect temperature and vibration data all the time. It will help our customers to improve production efficiency and stability.
We're willing to help customers to capitalize on the opportunities of smart manufacturing. Talk to us now! Or you can visit us directly at TIMTOS X TMTS exhibition booth #I0816

Tungsten steel industry customer


All Newsletters
....................................................................................................................................................................

Exhibition News

TIMTOS x TMTS 2022


Exhibition —

TIMTOS x TMTS Exhibition

Date
February 21-26, 2022

— Booth —
Taipei Nangang Exhibition Center┃Hall 1┃#I0816

Link
https://www.jainnher.com/news/TIMTOS-x-TMTS-2022.html

....................................................................................................................................................................

CCMT Shanghai


Exhibition

China CNC Mchine Tool Fair 2022 (CCMT Shanghai)

Date
April 11 - 15, 2022

— Booth —
Shanghai New International Expo Centre┃W3-B213

Link
https://www.jainnher.com/news/2022-CCMT-Shanghai.html


Latest News
....................................................................................................................................................................

Holiday Notice


Holiday
Our office will be closed on following dates due to Peace Memorial Day:
February 26(Sat.) – 28(Mon.), 2022
Your business is important to us and we’ll respond to you immediately after return to work. Thank you for your kindly understanding and continuous support!
