Newsletter Vol.39

May. 17 2022

News Letter

Newsletter Vol.39

Products | News | Video | Contact Us


Grinding Case


JHC-18S




Workpiece: brass instruments parts



Model: JHC-18S Centerless Grinding Machine



Capacity: OD Ø1~ Ø 100mm



Grinding wheel diameter: Ø455*205*Ø228.6mm



Regulating wheel diameter: Ø255*205*Ø111.2mm



Surface Roughness: 0.03µm



Surface roughness: RA 0.25



Regulating wheel speed: Servo motor 10-250 R.P.M variable speed



Suitable for multi-steps forming grinding simultaneously




In-feed or thru-feed grinding are both available depends on the requirement workpiece




Equip with our own design loading / unloading device to improve production efficiency






Applications: Automobile / Motorcycle / Bicycle parts┃Energy industry Precision Machine Tools┃Pneumatic and Hydraulic Components Electronics industry┃Optical Instruments┃Precision Medical Tools Recreation industry

More Applications
....................................................................................................................................................................

Machine Overview
| JHC-2416T-CNC6 Centerless Grinding Machine Solution |

JHC-2416T




The spindle adopts bearing type structure. No need to put an external lubricating oil tank makes machine very convenient for maintenance.




Machine design adopts symmetry direction feeding in grinding and regulating wheels. The 405mm large grinding wheel is capable of heavy grinding.




CNC controls feeding, dressing and compensation. It can improve overall quality, increase productivity and minimize the manpower requirements.






To equip with our own designed large loading / unloading device, machine is capable to grind maximum diameter 230mm workpiece. There’s no need to adjust the loading / unloading device when the grinding & regulating wheels wearing.




Suitable for precision parts industry such as: mold industry, machine tool parts, shock absorbers of automotive parts, camshafts and pump shaft.


More Products
....................................................................................................................................................................

Bulletin Board
| 2022 TIMTOS x TMTS Show Review |

Knock knock! Let’s find out what did Jainnher do in TIMTOS x TMTS this year. There were 4 kinds of grinding machines has been displayed including
Cylindrical JHP-2003CNC, Center hole JHG-1510NC2 that is suitable to equip with robot arm, Internal JHI-150CNC with HIWIN's Intelligent 4.0 ball screw installed and high production efficiency Centerless JHC-2424T-CNC6


TIMTOS1

TIMTOS2

General Manager Mr. Lai has attended the press conference which holds by HIWIN. It's a business alliance which dedicated to “advancing smart manufacturing technology” that consists of 30 companies from machinery industry. Mr. Lai has also attended to the mid-term presentation of "Intelligent Machinery Industry" which organized by Taiwan's IDB organization. We want to provide various solutions to help customers from different industries, and to show our strong spirit of corporate sustainability.

TIMTOS3

TIMTOS4

Due to the restrictions of the epidemic, the number of domestic visitors to the site has decreased. U.S. and European distributors have connected with our sales team via video calls instead of traditional face-to-face meetings. It's necessary to pay careful attention to the international affairs under the changeable global environment, but most of our customers are still optimistic on the potential of the market and our future cooperation. It was been our pleasure to serve all the customers in TIMTOS x TMTS this year, and hope to see you guys soon!

TIMTOS5

....................................................................................................................................................................
| Jainnher’s Spring Party |

In March 4th, Jainnher staff were celebrating the new year and expect new business development success.

Spring Party1

Spring Party2


All Newsletters
....................................................................................................................................................................

Holiday Notice


Holiday
Our office will be closed on April 30(Sat.) – May 2(Mon.), 2022
due to International Workers' Day holiday. Your business is important to us and we’ll respond to you immediately after return to work. Thank you for your kindly understanding and continuous support!
